Hybride IEM verbinden die positiven Eigenschaften von dynamischen und Balanced Armature In-Ears. Wer nicht nur die hochtonbestimmte Wiedergabe von Balanced Armature Treibern oder die sehr warme und ausgewogene Wiedergabe von Dynamischen Treibern bevorzugt, findet mit den hybriden In-Ear-Kopfhörern seine Lösung. Hybride IEM sind aufgrund der Kombination der beiden Technologien dazu in der Lage den Klang über den kompletten Frequenzbereich darzustellen.
Sowohl hochfrequente Klänge, als auch tiefwarmer Bass können von hybriden IEM plastisch und hochauflösend wiedergegeben werden. Einige Modelle lassen sich über Frequenzweichen den klanglichen Vorlieben anpassen.
FiiO FH11
1 DD+ 1 BA driver arrangement
New generation carbon-based 10mm cone
Specially tuned balanced-armature driver
Three-chamber acoustic cavity design
C-shaped acoustic flute
Extremely coherent sound reproduction
Strong bass, excellent clarity / Fine-tuned frequency response
Ergonomic triangular design / 0.78 mm 2-pin connector
High-purity, oxygen-free 120-core copper cable
Introducing the new FiiO FH11 dual-driver hybrid in-ear monitor from FiiO. It is part of the new "Bionic Conch" product series, which aims to deliver high-quality sound and exquisite aesthetics that are far above its price range. The FH11 features a carbon-based 10mm dynamic cone driver and a specially tuned Balanced Armature driver housed in a three-chamber acoustic chamber. The pair features a C-shaped acoustic flute design that significantly improves the sound quality of the pair. Prepare to experience enhanced sound with rich features with the FiiO FH11.Pure sound with dual-driver hybrid setupWith many years of experience in developing high-quality audio products, FiiO has developed the FH11 as part of its 'Bionic Conch' series of affordable in-ear monitors. The FH11 features an exquisite architecture that promises high-quality sound reproduction with detailed low-end response. The pure high-resolution audio produced by the FH11 complements various genres such as rock, pop, etc.Specially designed 10mm carbon-based dynamic driverFiiO has equipped the FH11 with a 10mm carbon-based diaphragm dynamic driver. The driver was developed after an in-depth study of the performance of higher-end models such as the FF5 and FH15. This new carbon-based diaphragm has a low weight and extremely high tensile strength. It provides a clearer sound with faster transients and less distortion in the output signal.Hear every detail with easeUsing a custom Balanced Armature driver on each side, the FiiO FH11 accurately reproduces every minute detail in music. It delivers crisp treble reproduction with amazing clarity and retains enough warmth to complement the powerful sound of the carbon-based DD unit.Three-chamber acoustic cavity designIn a hybrid IEM with multiple drivers, the structure of the acoustic cavity can make or break the overall performance. With its expertise, FiiO has designed the FH11 with a three-chamber acoustic structure that provides enhanced sound reproduction with the lowest distortion and delivers a significant performance boost. With a properly implemented acoustic damping structure, the FH11 maintains the correct air pressure in each chamber, enabling precise and accurate performance from the two drivers.C-shaped acoustic flute designIn addition to the three-chamber design, the FiiO FH11 also features a C-shaped acoustic flute structure. It manages the air movement inside the pair and uses to enhance the sound. It improves bass clarity and makes the set more responsive.Exquisite die-cast zinc alloy cavitiesThe FiiO FH11 IEMs have a refined and high-quality appearance. The pair is made of exquisite die-cast zinc material. It looks absolutely beautiful and has a pleasant aesthetic that contributes to a comfortable fit for most users.Technical dataImpedance: 24Ω@1kHz.Sensitivity: 111dB/Vrms.Frequency response: 20Hz-20kHz.Connector type: 0.78mm 2-pin male.Connector plug: 3.5mm.
FiiO FH15 - the new hybrid IEM benchmark
Well-founded breakthroughs from more than 1570 days of development time
1 dynamic, 3 BA driver
10mm dynamic carbon-based cone driver
Knowles BA CNC aluminium alloy construction
Notch filter
Patented S.Turbo design 3 tuning filters included
152-core silver-plated monocrystalline copper cable
FiiO HS18 ear tips
1 dynamic and 3 balanced-armature drivers in hybrid design- Robust bass, powerful and musical, like a personal concert in the ear
Dynamic driver with 10 mm carbon-based diaphragm
Completely redesigned driver from FiiO, fast transients, always alive Knowles BA driver
Dedicated Knowles ED-30262 for mids, two Knowles RAD-33518 for highs
CNC aluminium alloy construction
High-quality materials, meticulous craftsmanship, for a luxurious feel
Notchfiltger technology for smoother highs, with denser and more powerful mids
Patented S.Turbo design Improved bass, more robust and deeper bass
3 tuning filters included More sound flavours to choose from
152-core silver-plated monocrystalline copper cable for full-bodied sound. Delivers fast, beautiful tones
FiiO HS18 ear tips Included - Sizes S/M/L, only 0.4 mm thick
4 years fine tuning
Move forward with the new reference-class hybrid HiFi IEMs.
In 2018, FiiO has implemented cutting-edge technologies such as TRISHELL housing, S.Turbo acoustic design and a 10mm polymer composite driver into the FH5, providing listeners with a rich and detailed listening experience. After its launch, the FH5 was praised by users for its excellent deep bass and high resolution in an affordable package. It has been on the market for more than 50 months and is a testament to our commitment to great sound. The FH5 has also been recognised by the industry - winning awards at the 2019 Summer and Winter VGP and the 2020 VGP.
In 2021, FiiO launched the FH5s/FH5s Pro, equipped with interchangeable filters that allow users to better customise their sound. This time, we wanted to go back to basics and take on the daunting challenge of taking the sound quality of the FH series to a new level.
After four years of development and three generations of other product launches, countless experiments and restarts, an IEM has emerged that is the result of innovation after a lengthy development process. Based on a wealth of objective data and subjective listening tests, FiiO has not only developed a brand new 10mm dynamic driver with a carbon-based diaphragm, but also combined it with other cutting-edge technologies in the FH15 to give you a music experience as if you were right there with the artists.
The VGP, short for Visual Grand Prix, is an event organised by Japanese publisher Ongen Publishing. The VGP was launched in 1984 and over the course of 30 years has earned a reputation as the "Oscars of audiovisual engineering", widely recognised in Japan and throughout Asia.
Message from the engineers
FiiO presents FH15 "Among our products, the FH5 is a mid-range product with a sound signature that appeals to many. It offers a rich sound with lush voices, perfect for detailed classical and instrumental music.
In the four years and three product generations since the FH5 was launched, we found that users wanted a brighter sound and even higher resolution in the treble, without sacrificing the FH5's sound, which is suitable for all types of music.
That's why we used the FH5's sound as a reference when tuning and developing the FH15's drivers.
The lower frequencies are handled by our all-new 10mm dynamic driver with carbon cone. The midrange frequencies are produced by a special Knowles ED-30262 BA driver, while the treble is taken care of by a Knowles RAD-33518, which provides a much improved transparency of sound. The bass, midrange and treble have been tuned to make the FH15 sound good across all genres of music.
For those who want to fine-tune the sound of instrumental music focusing on specific instruments such as piano, guitar, violin, etc., the FH15 offers interchangeable filters with distinctly different sounds."
--Joseph Chief Engineer of FiiO IEMs Research and Development Centre.
Newly developed 10mm dynamic driver with carbon-based diaphragm
The FiiO development team has chosen a carbon-based material for the diaphragm of the dynamic driver, which provides excellent transient response.
The low weight, high stiffness and high internal resistance of carbon mean that the dynamic driver can quickly start and stop movements as it responds to changes in the input signal. The high internal damping of the carbon-based diaphragm's thousands of stacked and woven cross-fibre filaments means that the edge and centre of the diaphragm can move quickly in the same direction - minimising the driver break-up that occurs when different parts of the driver move out of sync. This results in less distortion and ultimately a clearer sound.
10mm--Large dynamic driver --Tensile strength 9 times that of steel 1/4--For the same volume ¼ lighter than beryllium 4.
Custom Knowles BA driver -Like you've been to a concert.
For midrange frequencies, the FH15 uses the custom Knowles ED-30262 BA drivers.
These drivers work in conjunction with specially placed tuning holes in the FH15's cabinet, allowing for richer vocals and a more musical sound. The treble is reproduced by 2 Knowles RAD-33518 BA drivers, which offer high resolution in the treble and capture every last detail in the music for a truly airy sound. These drivers ensure that you have a listening experience as if you were there with the artists performing.
Individual notch filter
Richer sound for more enjoyable listening "For hybrid headphones with multiple drivers, finding the right combination requires looking at the drivers not only as a unit, but also independently. We first tuned each driver separately, as if it stood alone, and then combined the drivers scientifically. This methodical process allowed us to achieve our sonic goals for the FH15."
--FiiO IEM's R&D Centre
The Notch Filter was designed specifically for the FH15, giving it its distinctive sound. A Helmholtz resonator is designed to work with the ED drivers in the mid-frequency range. When the sound wave is at a certain frequency for which the Helmholtz resonator is designed, the volume of sounds at that frequency is amplified as the resonator concentrates and resonates that frequency. A look at the frequency response curve shows that the frequency response between 1 kHz and 4 kHz has been improved, resulting in denser sounding mids that give voices and instruments more realism without sounding thin. In addition, the resonator is connected to a thin port to eliminate unwanted resonance peaks and overlapping frequencies produced by the different drivers to achieve better coherence between the drivers while eliminating sibilance. This is the notch filter technology used in the FH15.
S.Turbo patented design
Scientific hi-fi with optimised frequency response Balance between bass, midrange and treble as well as clarity are the ideal sound goals of many audiophiles, but this is easier said than done with hybrid IEMs with multiple drivers. The reason is that the different drivers produce frequencies that overlap and interfere with each other. Therefore, crossovers are needed to split the frequencies to be generated between the drivers to achieve a clear, coherent sound. Therefore, the RC circuit design is used to manage the crossover in the higher frequencies, using the high-frequency driver with the higher resonance frequency as the high-pass filter. To manage the crossover in the lower frequencies, the traditional low-pass filter RC circuit requires components that take up too much space in the inherently small in-ear monitors. However, this did not stop FiiO from finding a solution that would ensure high quality bass frequencies produced by the drivers. The development team worked with an understanding of the basic principle of sound waves. The higher the frequency of the sound wave, the shorter the wavelength and the faster the attenuation. The FiiO development team worked with this basic principle and came up with the patented S.Turbo acoustic design*.
*Patent No: ZL2018211416279
To achieve our sound goals for the FH15 in the mids and highs, we filter the higher frequencies produced by the woofer in a low-pass filter called the S.Turbo Acoustic Design. This design reduces the overlap in frequency response between the woofers and midrange drivers, providing more coherence between the different drivers and a more balanced frequency response for a cleaner, more natural sound.
Reboot your senses
A fusion of classic and modern design The FH15 is a reinterpretation of in-ear monitor design with a dragon scale motif in a medium-sized oval shape that fits the ear perfectly for added comfort. The modern, minimalist lines blend seamlessly with the classic dragon scale design elements, giving the FH15 a vibrant, rugged look that redefines your idea of what an IEM can look like.
Aluminium alloy construction
5-axis CNC - The FH15 is constructed from aluminium alloy which, combined with the dragon scale design elements, gives the IEM a unique, exquisite feel. Due to the small surface area of the FH15 faceplate, precise 5-axis CNC machining ensures that every texture on the faceplate is appropriately three-dimensional and eye-catching. The CNC machining uses fine 0.8mm diameter milling heads to ensure that the textures on the front panel are both attractive to the eye and luxurious to the touch.
Come on, let me be in charge of the sound
Interchangeable audio filters
3 pairs of audio filters are included, each pair providing a different sound depending on the density of the materials in the filter:
Red filter - boosted bass, for a powerful sound
Black filter - balanced sound, transparent and clear
Green filter - exquisite highs, high resolution
*Green filter is pre-installed, the other filters are on the included storage sheet
Brand new FiiO HS18 earplugs
Included with the FH15 are 3 pairs of the FiiO HS18 ear tips. With a thickness of only 0.4 mm, the HS18 are extremely comfortable to wear. The HS18s also feature a large opening that matches the size of the earcup to minimise the barrier between the earpiece and the eardrum, ensuring maximum detail and less sound loss at high frequencies.
A high quality cable of great value
The FH15 comes with a 152-core, silver-plated, monocrystalline copper cable with 8 strands. The stranded braid specifically reduces skin and proximity effect, resulting in lower eddy current losses and therefore improved high frequency resolution. In addition, the audio connectors are interchangeable and 3.5mm/4.4mm connectors are included. *The interchangeable audio jack is officially patent pending by FABRILOUS.
Specifications
Wearing style: Over-the-ear
IEM Housing construction: Aluminium alloy Dynamic
Driver: 10 mm carbon-based cone (low frequencies)
BA driver: Knowles RAD-33518*2 (high frequency)
Knowles ED-30262 (midrange)
Frequency response: 10Hz-40kHz
Impedance: 16 Ω @ 1kHz
Sensitivity: 112dB/mW@1kHz
Cable: 152 wires of high-purity, silver-plated, monocrystalline copper.
Cable length: Approx. 1.2 m
Weight of the device: Approx. 6.6g (without cable)
Rich accessories:
3.5 mm interchangeable plug*1 Pre-installed 4.4 mm interchangeable jack*1
Tweeter filter*2 (green ring) Pre-installed Balanced filter*2 (black ring) Bass filter*2 (red ring)
MMCX tool*1 Carrying bag HB1*
1 cleaning brush*
1 HS18 earplug*
3 pairs (SML) Balanced Earplugs*
3 pairs (SML) size M pre-installed vocal earplugs*
3 pairs (SML) Bass earplugs*
3 pairs (SML) Double flange earplugs*
2 pairs (M) Foam earplugs*
2 pairs (M)
Instruction manual*1
Flagship in-ear headphones 2 dynamic 6 BA 8 drivers IEM's push-pull dual dynamic driver units Custom Knowles enhanced mid-BA drivers Titanium+7000 aluminium construction Semi-open design Mid-frequency notch filter Four-way acoustic design Patented S.Turbo design, improved bass extension, more robust bass 3 interchangeable audio filters enabling different listening experiences High-purity monocrystalline sterling silver cable, 8 strands with a total of 224 wires Co-developed with Tokyo Onkyo Ltd. Rubycon film capacitor crossovers in audiophile quality Physical pass-through, refined frequency division Optimised wearing ergonomics Interchangeable 3.5/4.4 mm plugs Flagship sound Three years ago, the FH9 was launched, the first high-end hybrid headphones from FIIO. With its energetic dynamics, wide soundstage and pleasant sound quality, it was enthusiastically received by hi-fi users worldwide. It gradually became known among audiophiles as a great example of ‘balanced headphones’ and far exceeded expectations in terms of popularity. It is still a competitive headphone on the market today. The new FIIO FH19 from FIIO is a significant upgrade that incorporates a lot of user feedback. It retains the distinctive sound and premium build quality of the FH9 and has also been developed in partnership with Tokyo Onkyo Ltd. in Japan and Knowles in the USA. It features a truly high-end acoustic design, with richer and fuller mids and a more robust yet flexible bass. In addition, the fit has been redesigned and optimised based on the characteristics of the human ear, so you can enjoy flagship-level comfort. The top, further improved The new FIIO FH19 is equipped with two 13.7mm dynamic drivers and six balanced armature drivers, matching the flagship. The bass is reproduced by a completely new push-pull dual dynamic driver unit, which was developed jointly with Tokyo Onkyo Ltd. in Japan. This driver is characterised by significantly improved extension, cohesion and speed in the low frequency range. The mid to high frequencies are handled by specially adapted, improved Knowles Balanced Armature drivers for the midrange, achieving greater sound energy density for rich and delicate vocals that are wonderfully musical without sacrificing detail. As the cones move back and forth, the overall direction of movement of the two dynamic drivers remains consistent due to the push-pull arrangement, ensuring phase consistency. This effectively doubles the driving force and allows the diaphragms to damp each other with air. As a result, the dynamic drivers exhibit more stable movement and completely suppress any residual sound after the end of the audio signal. Compared to typical dynamic drivers, push-pull dual dynamic drivers require only half the amplitude to reach the target sound pressure level. This results in lower cone excursion, which significantly improves linear drive performance and further reduces intermodulation distortion, allowing the driver unit to deliver a cleaner sound. Customised Knowles Enhanced Mid-BA Drivers The FIIO FH19 uses six Knowles Balanced-Armature drivers as mid and high frequency units. To achieve an even higher level of vocal sound quality, FIIO has worked with Knowles to develop a custom balanced armature driver with enhanced midrange. By adding acoustic vents in the rear cavity of the driver, the mid-frequency driver gains more sound energy compared to typical mid-frequency drivers. This brings out the benefits of the midrange driver even more, resulting in rich and smooth vocals that sound as immersive and realistic as if the singer were standing right next to you. 7000 Series titanium and aluminium construction The FIIO FH19 boasts a build quality worthy of a flagship speaker, helped by its titanium centre frame. Its luxurious feel and uniquely charming titanium colour give it a premium look. As the part of the headphones that is touched the most, the rigidity and corrosion resistance of the pure titanium metal bracket thoroughly protects the rest of the headphone housing and makes it resistant to everyday wear and tear. The FIIO FH19 uses 7000 series aluminium*, which ensures a robust and resistant housing while reducing the weight of the headphones. Thanks to this aluminium, the FH19 offers a comfortable wearing experience even with more drivers and a more complex acoustic design. *7000 series aluminium alloy is widely used for aircraft fuselages, wings and other important components. It has high strength, rigidity and corrosion resistance. Fatigue-free listening, large sound stage Semi-open design The semi-open design was highly praised in the FIIO FH9, FH7S, FH5S and FD5. In the FH19, this proven semi-open design is used again and has been specially adapted to combine with FIIO's balanced pressure relief technology for the front and rear cavities - the result is a more natural and relaxed sound with a wide sound stage. This design efficiently equalises internal air pressure, eliminating the feeling of pressure on the eardrum, which also helps protect your hearing. Enjoy long listening without fatigue. Mid-frequency cut-off filter The FH19 features a variety of different drivers and acoustic design principles. The scientific tuning of the individual parts so that they form a harmonious whole is the essence of high-level tuning. To achieve this, the FIIO development team has developed a special ‘mid-frequency cut filter’ for the FH19 hybrid earphones. Further enhanced mid-range tests have shown that the FH19's mid-frequency cut filter not only retains the high resolution and clarity of the BA drivers, but also increases the sound pressure level in the mid-frequency range. This makes the vocals denser and fuller while ensuring a smooth transition between the dynamic driver and the BA driver for the mid frequencies. The FH19's mid-frequency cut-off filter effectively filters out the high-frequency 8 kHz peaks generated by the mid-range drivers. This reduces the overlap between the sound produced by the midrange and tweeter drivers, eliminating sibilance while ensuring high sound quality. The mid-frequency cut-off filter can also advance the crossover point of the balanced armature units. This ensures that these drivers have a truly independent frequency range and there is no interference with the other drivers, allowing the tweeters to perform to their full potential. The working principle of the FH19's mid-frequency cut-off filter: When the frequency of the sound wave is close to the natural frequency of the resonance chamber, the inner wall of the resonance chamber and the air generate vibrational friction, which converts the sound energy of certain frequency bands into mechanical and thermal energy, thereby consuming sound energy and achieving a sound absorption effect. Conversely, the resonance effect in the cavity is weaker if the frequency of the sound wave is far away from the natural frequency of the resonance chamber, resulting in less sound absorption. This principle forms the basis for the operation of the FH19's mid-frequency cut-off filter, which adjusts the sound produced by the mid-range drivers and achieves a physical pass-through effect. Focusing on small details to achieve big improvements Suspended voice coil To achieve flagship-level driver performance, the FIIO FH19 utilises a suspended voice coil. With this design, the voice coil leads are routed directly from the centre hole underneath the cone, allowing them to float in the gap. This avoids unnecessary contact and prevents additional adhesive load. Compared to conventional diaphragms*, the floating voice coil design ensures smooth and gentle diaphragm movement, minimising interference from other factors and fully exploiting the diaphragm's inherent potential. *Conventional diaphragms often use special adhesives to bond the voice coil to the diaphragm surface. However, this approach not only increases the overall weight of the diaphragm, but can also lead to a dynamic imbalance during dynamic movements of the driver. Uneven local weight distribution can lead to vibration irregularities, change the compliance of the cone and even cause distortion due to voice coil scraping. This ultimately affects the overall performance of the driver. Scalpel-like accuracy Rubycon audiophile-grade film capacitor crossovers The FH19 is equipped with the same high-precision Japanese film capacitors as the FA19, which offer exceptional accuracy in phase matching and have been developed with the utmost care for sound quality. While conventional resistor-based crossover components typically have an accuracy error of around 1%, the FH19 achieves an impressively low error rate of 0.1%. In addition, the FH19 not only achieves more precise crossover points compared to conventional ceramic capacitors, but also effectively improves the resolution in the high frequency range and results in a more detailed sound overall. Acoustic four-way design "While the basic design is derived from the FH9, the FH19 builds on and surpasses its predecessor by updating the bass and midrange drivers and implementing them in a more precisely controlled four-way crossover design. Special push-pull dual dynamic driver units are used in the low frequency range, and a ‘Turbine Low-Frequency Boost Technology’ is used for physical low-pass filtering for relaxed yet natural bass. For the mid frequencies, the FH19 introduces an innovative ‘3+1 semi-open’ acoustic layout with balanced armatures. This is complemented by a newly designed resonance chamber that allows for two separately managed mid-range areas, resulting in richer and more emotional mids. For the high frequencies, the FH19 retains the coaxial design with an acoustic guide, but also incorporates audiophile-quality Rubycon film capacitors. This combination enables high resolution with excellent high frequency response." Chief Engineer of FIIO IEM's R&D Centre Turbo-charged energy Patented S.Turbo design Inspired by turbochargers in super sports cars, the FIIO development team has created the patented S.Turbo acoustic design. This design ingeniously utilises the properties of sound wave guidance and improves bass performance through a turbine-shaped structure. The result is a deep and lively bass. In addition, the design skilfully filters out excess mid to high frequencies from the dynamic driver, ensuring smooth transitions between the low and mid to high frequencies. The result is a powerful and robust sound. Patent number: ZL2018211416279 Interchangeable audio filters As befits an IEM flagship, the FH19 has three pairs of interchangeable audio filters. Each filter has a different internal attenuation and mesh density, so you can customise the sound to your preference: Red audio filter - Boosts low frequencies and provides powerful and impressive bass Black audio filter - Provides a balanced sound that is clear and transparent Green audio filter - Delivers fine and detailed highs *Green filter is pre-installed. The other filters are included in the carrying case. Top-class comfort Optimised wearing ergonomics 10° ear cup angle Based on user feedback and numerous optimisations, the angle between the ear cup and the wearing surface along the Y-axis is exactly 10°, while the length of the ear cup remains unchanged. This adjustment means that the earphones fit even more precisely in the ear canal, which significantly improves both wearing comfort and stability. Gap-free, comfortable fit, the FH19 has a completely new, more three-dimensional rear recess design. Numerous tests led to numerous ergonomic optimisations, such as ear-friendly protrusions with a thickness of approx. 1.4 mm, which ensure a firm and stable fit by minimising any unwanted movement. The brand new design of the FH19 back panel features a slight reduction in thickness - approximately 1 mm - in the area corresponding to the fold of the human ear. This structural design significantly reduces the feeling of pressure and compression on the ear from the earphones. In combination with the excellent housing materials, the FH19 disappears into your ears while delivering a first-class sound. Pure silver for pure sound The FH19 comes with a high-purity pure silver cable as standard. Each of the 8 strands consists of 28 wires, totalling 224 wires. Each individual wire is insulated with enamel and the cable is braided into strands. The outer jacket is made of imported, transparent and environmentally friendly TPU, which enhances the transparent appearance of the cable. In addition, this material effectively prevents the cable from yellowing with prolonged use and becoming stiff at low temperatures. *The cable is identical to the LC-RD Pro 2022 Straight, interchangeable twist-lock audio plugs Supports 3.5/4.4 mm plugs and features extended stainless steel MMCX plugs *Patent for interchangeable audio plugs licensed by FABRILOUS. Listen the way you want 22 pairs of ear tips included As befits a flagship model, the FH19 comes with 22 pairs of ear tips in different shapes and sizes* to give you a comfortable listening experience no matter what your preferences are. In addition to the popular HS18 and SpinFit ear tips, the new HS18 silicone ear tips are also included. Specifications Headphone type: Hybrid in-ear monitors with dynamic and BA fittings Frequency response: 8Hz-40kHz Impedance: 16Ω@1kHz Sensitivity: 109dB/mW@1kHz Cable type: 8 strands with a total of 224 wires of high-purity pure silver Length of cable: Approximately 1.2m Weight of headphone unit: Approximately 12g (without cable) Earphone connection: Extended MMCX Audio plug: Straight twist-lock plug3 pairs of HS20 silicone ear tips (S/M/L) 3 pairs of HS18 ear tips (S/M/L) 3 pairs of SpinFit ear tips (S/M/L) 2 pairs of foam ear tips (M) 3 pairs of bass ear tips (S/M/L) 3 pairs of balanced ear tips (S/M/L) (size M pre-installed) 3 pairs of vocal ear tips (S/M/L) 2 pairs of dual flange ear tips (M) 1x HB7 carrying case 1x cleaning brush 1x MMCX quick release 1x magnetic cable clip 1 set of audio filters red/black/green 1x pure silver earphone cable with interchangeable plug 3. 5/4.4 mm 1x quick start guide
FiiO FH3 - Hybrid in-ear headphones with S.TURBOFiiO FH3 in summary: The FiiO FH3 in-ear headphones come with a host of innovations and improvements, all of which guarantee an even more balanced and natural sound image. Hybrid construction of dynamic and BA drivers, beryllium coating on the dynamic driver and much, much more.The highlights of the FiiO FH3 in-ear headphones at a glance: The best of both worlds - hybrid of dynamic and BA drivers. Beryllium-coated driver - Crisp and precise bass Patented S.TURBO acoustic design - Provides a clean sound image High quality headphone cable - 96 strands with silver plating Elegant and robust housing - CNC machined from aluminiumBalanced Armature + Dynamic Driver = Perfect SoundFiiO FH3 driverThe in-ear, i.e. the headphone that is placed in the ear, dominates the worldwide market, but there are certainly people who do not like the feeling in the ear and therefore reject this design.If you don't fancy in-ear headphones, but are still looking for extremely compact headphones and don't want to compromise on sound quality, take a look and listen to the FiiO EM5. These also plug into the ear, but only rest on the ear canal (instead of being plugged in) and still deliver excellent sound.Beryllium-coated driver - combining the extremesFiiO FH3 diaphragmFor first-class sound, drivers are needed that are actually supposed to combine completely contradictory characteristics. On the one hand, they should be as stiff and resistant to distortion as possible, but on the other hand, they should be as light as possible so that they can react to impulses as quickly as possible and reproduce the music signal faithfully.Beryllium solves this problem. On the one hand, it is extremely strong (4x stronger than steel) and effectively hardens the 14.2 millimetre diaphragm in the headphones against unwanted distortions in the music signal, but at the same time it is wonderfully light, so that the impulse fidelity of the driver is maintained.Patented S.TURBO design - With integrated pressure equalisationFiiO FH3 S.TurboThe S.TURBO design consists of a bass reflex tube with an impressive length of 41.5 millimetres, shaped like a scroll inside the headphones. But not only the bass benefits from the design, but also the high frequencies, because unwanted high frequency components are effectively filtered out on their way through the tube. The whole thing happens so effectively that FiiO calls it a true 3-way design with electronic and physical crossover.In addition to the "snail" in the headphones that stabilises the bass, there is another clever feature: two outlets per earphone that regulate pressure inside the headphones, ensuring a balanced and clean sound.High-purity silver throughout the headphone cable - uncompromising qualityFiiO FH3 headphone cableWhen it comes to music, every detail counts. Just like the 1.20 metre headphone cable used, for example. FiiO knows this and makes no compromises. For the connection from the plug to the headphones, 96 individual conductors of monocrystalline silver-coated copper are used, all of which together ensure a lively and clear sound.Aircraft-grade aluminium and magnesium housing - precision engineeredFiiO FH3 HousingThe housing of each earphone in the FiiO FH3 in-ear headphones is precision CNC-machined. It takes 4340 (!) individual steps to create the perfect product.But the housing is not only durable and of high quality. It also incorporates all the experience gained with FiiO's previous in-ears, making it even more comfortable to wear.A difference you can see and feel.Maximum flexibility with the headphone jack - with one clickFiiO FH3 headphone jackWith the FiiO FH3's built-in MMCX connector, any headphone cable can be easily clicked, unplugged and swapped.Whether you want to use a different headphone cable with a larger or smaller jack plug, or use "Bluetooth cables" such as the FiiO UTWS1 or FiiO LC-BT2: All possible in no time at all.Lots of accessories included - Various ear tips includedFiiO FH3 accessoriesEvery ear and every listening taste is different. That's why the FiiO FH3 comes with a whole stack of different pairs of ear tips in various sizes and sound settings. There are three pairs for bass lovers. Three pairs for those who prefer a balanced sound reproduction. And three pairs for all those who appreciate a high-frequency reproduction.And for very sensitive ears, there are also two super-soft pairs of foam tips. Thanks to body heat, these adapt elegantly to the inner ear and guarantee unadulterated listening pleasure even for many hours at a stretch.
FiiO FH5s - The in-ear headphones for the big stageThe FiiO FH5s in-ear headphones are not only an absolute eye-catcher with their elegant design, but are also technically extremely appealing and packed with clever ideas. With its "2+2" driver concept, tuning switches for sound adjustment and TRISHELL housing, FiiO once again proves that first-class engineers with a love of music were at work here. Let's go!The highlights of the FiiO FH5s at a glance: 2+2 drivers work in tandem - Dynamic meets Balanced Armature Semi-open cabinet concept - pressure in the bass; and not in the ear TRISHELL-Acoustic-Design - No chance for resonance and distortion Customisable sound - 3 switches for 8 settings High compatibility and flexibility - For connection and cables2+2 drivers in tandem - Simple maths for the best soundThe FiiO FH5s uses a total of four drivers - two dynamic drivers and two balanced-armature drivers.The dynamic drivers in detailFiiO FH5s driver diagramThe woofer uses a 12-millimetre beryllium-coated driver encased in an extremely rigid yet flexible polyurethane polymer surround. The sonic advantages of beryllium are obvious. On the one hand, it is considerably lighter, but also much stronger than titanium or aluminium. With its high internal damping, beryllium minimises disturbing resonances that would distort the sound.The woofer is driven by a powerful N52 neodymium magnet, which at 1.5 Tesla represents the current maximum magnetic force in a compact permanent magnet.The midrange is also driven by a beryllium-coated dynamic driver, but this time with a diameter of 6 millimetres. There, the dynamic driver provides clear and realistic vocal reproduction that blends harmoniously with the rest of the sound image.The Balanced Armature drivers in detailFiiO FH5s Knowles TWFK-30017Connoisseurs already know, but balanced-armature drivers are incredibly precise, responsive and accurate. Their disadvantage, however, is that they only do their job perfectly in a fairly small frequency range. Because of their compact dimensions, balanced-armature drivers are quite easy to "stack" and combine several in one pair of headphones. This is the case in the FiiO FH5s.Here, two balanced-armature drivers share the tweeter and the super-tweeter - and they do so with the highest precision and first-class timing.Semi-open cabinet - closed, high-resolution sound imageThese headphones really pack a punch in the bass. Both in the sound image and physically. In a completely closed housing, this air pressure would have no chance to escape and would inevitably spread to the sensitive inner ear. And thus cause a certain fatigue during longer listening sessions.But the semi-open design has other advantages. For one thing, an open, wide soundstage, since the sound can spread out realistically - similar to the original recording. Secondly, the shape of the air outlets is reminiscent of a dragon's scale, giving the FiiO FH5s a unique look.Intricate TRISHELL design - Because every detail countsOf course, you can make a headphone housing out of two halves of plastic and glue them together. But you can also do it like FiiO did with the FH5s and approach the subject with the greatest possible care. With a "sandwich construction" of three individual parts made of aluminium/magnesium, milled in an elaborate CNC process. The parts themselves are in turn connected to each other at three points, and together they ensure that resonances and distortions are reduced to a minimum.Music as individual as you are - in the blink of an eyeFiiO FH5s enclosure with switchWhether you prefer your music bass-driven, with more detail in the high frequencies or with a focus on voices, with the FiiO FH5s it's just a click away. This is done via the discreet dip switches for bass, mid-range and treble that are elegantly embedded in the headphones.Of course, the effects can also be combined, so that a total of eight different settings are possible with the three switches. So music always sounds the way YOU like it.Versatile and flexible - even with the connectionsFor the connection from the jack plug to the headphones, 120 individual conductors made of copper coated with monocrystalline silver are used, all of which together ensure a lively and crystal-clear sound. And to top it all off, the headphone cable offers not one, but three different connection options via the included interchangeable connector plugs. 2.5 mm balanced jack, 3.5 mm jack and 4.4 mm balanced jack are fitted to the cable in no time at all.
And you also have all the options in the headphones themselves, since the cable is not permanently welded, but realised in the MMCX standard. This means that you can replace the already very high-quality headphone cable with another cable of your choice with just a flick of the wrist.Packed to the brim with accessories - everything your heart desiresFiiO FH5s accessoriesSound is individual, and so are the ear tips on the FiiO FH5s. You can choose from three different Ear Tips with bass-emphasised character, balanced character and voice-emphasised character. Each comes in sizes S, M and L. For noisy environments, there are two pairs of Bi-Flange Ear Tips (S and L) and three pairs of Foam Tips for particularly sensitive ears.Also included: the practical FiiO HB5 storage box, a cleaning brush for cleaning after longer use and the Final MMCX ASSIST. Don't you know it? You'll learn to love it when you try to disconnect the MMCX cable from the headphones. Promise.
FiiO FH7S - Welcome to the new S-Class.
The FiiO InEar headphones FH7S in summary: The FiiO FH7S scores with its 3-way design with four Balanced Armature drivers, the dynamic driver made of Diamond-like Carbon as well as the intelligent tuning filters for a customizable sound. High end at an affordable price.
The highlights of the FiiO FH7S at a glance:
- All roads lead to Rome - And three to excellent sound. - Everyone gets what they need - Dynamic DLC driver + Balanced Armature - Diamond-like Carbon - Ultra-firm, arrow-quick and dust-dry bass - Integrated turbocharger - S.TURBO V2.0 provides perfect bass - The sound of your life - Three tuning filters included Five drivers for one result - Uncompromisingly good sound In principle, even a single diaphragm can reproduce the complete frequency range in an in-ear headphone. But the FiiO FH7S is ultimately not about fundamentals, but about excellence.
DLC meets Balanced Armature - With lots of know-how And so five (!) drivers are used in the FH7S. For each frequency range a separate specialist, which was developed and optimized exclusively for its task. And so a pair of SWFK-31736 balanced-armature drivers take care of the high frequencies, a pair of DFK balanced-armature drivers take care of the midrange, and a dynamic "DLC" driver (short for "Diamond-like Carbon") provides pressure and structure in the bass. And as usual, FiiO leaves nothing at all to chance when it comes to the drivers. If Knowles is already one of the best balanced-armature manufacturers in the world, FiiO did not miss the opportunity to participate in the development and contribute himself. And the development of the Diamond-like Carbon driver is entirely in-house.
Diamond-like Carbon - Shining appearance in the FiiO FH7S Balanced Armature drivers are incredibly precise and are therefore the first choice for excellent sound. Except in the bass range, because here they can't generate the necessary excursion. So an adequate alternative had to be found that could keep up with the BA drivers in terms of sound. And since they didn't really find anything on the market, FiiO sat down and developed a suitable driver themselves: the dynamic 13.6 millimeter "Diamond-like Carbon" driver. What exactly distinguishes this driver is already in the name: a high-strength structure, similar to a diamond. This is absolutely necessary, especially in the bass range, so that bass sounds not only powerful and deep, but also precise and structured, without clanking or distorting. And that's where the physical properties of carbon come in handy. On the one hand, this material is super light and has high internal damping, but at the same time it is extremely strong and stable, which makes it the perfect material for bass cones. The only downside: it's expensive.
A stylish dwelling - With intelligent, sound-rich ideas.
At first glance, the FiiO FH7S looks like a piece of technology from the future. And it is a bit, considering how many innovations have gone into it.
Larger stage and more relaxed listening
The 2nd generation semi-open design significantly further improves airflow in and out of the cabinet - which means an even more balanced soundstage. In addition, the inevitable air pressure on the listener's inner ear is significantly reduced, guaranteeing many hours of unclouded music enjoyment and significantly improving stage imaging.
More beautiful voices thanks to notch filter
Voices are a real challenge in sound reproduction. Often there is the dreaded "hiss" on the sibilants, especially with S sounds. This is caused by unwanted resonances that are mixed in with the actual music signal and cause a sharpness or harshness in the sound image.
The precisely calculated notch filter in the FiiO FH7S ensures that these unwanted resonances do not even find their way into the ear canal, but are caught beforehand. What remains is the pure, unadulterated music signal and a completely relaxed sound.
S.TURBO technology - clean and structured bass guaranteed Bass reflex tubes are not only found in speakers, but also in (miniaturized) form in in-ear headphones like the FiiO FH7S. However, this is not simply a tube, but the patented S.TURBO design. The bass reflex tube is shaped like a turbine, through which the sound, or rather the air excited by it, is precisely accelerated and directed. This concept gives, for example, drums significantly more authority and precision at the same time.
Everybody hears differently - the FiiO FH7S helps you to do so Everyone likes their music differently, and of course FiiO knows that. And so that you do not now need different headphones for different music genres and tastes, the FH7S comes with three different sound filters with which you can create your own personal sound. So there's a dynamic filter that adds more fun bass, a balanced filter that balances bass and treble, and a filter that favors treble and adds even more detail to the soundstage.Now you just have to decide what you like best.
Wearing comfort has also been thought of With many other headphones, the cable simply hangs down on the headphones and thus once again contributes its share to the perceived weight. Not so with the FiiO FH7S. There, the cable is routed over the ear, which not only relieves your ear of the weight, but also at the same time still provides a comfortable yet firm fit in the ear. Whether you're sitting relaxed on the sofa enjoying music or really working out in the gym: The FH7S stays securely in place.
Screwing instead of plugging - And that at the highest level Of course, the FiiO FH7S can only play back what it receives as a signal from the source. And so that nothing goes wrong on the way from the player to the headphones, FiiO has also thought of the matching headphone cable. At its core, this is a high-quality copper cable that has been coated with monocrystalline silver. Every single one of the 152 strands in the cable. A clever detail here is that you can choose between the 3.5 millimeter and 4.4 millimeter jack plugs included in the scope of delivery. And these are not simply plugged on or pushed into each other, but securely screwed to the actual cable. This guarantees that no note is lost.
Accessories for all situations - Gigantic scope of delivery In addition to the high-quality headphone cable, the FiiO FH7S also comes with plenty of other practical accessories. Such as the silicone ear tips FiiO HS18, which celebrate their premiere in the FH7S. What's special about them: The part that touches the ear is just 0.4 millimeters thick and thus adapts perfectly to the individual shape of the ear. Once again, hours of unadulterated listening pleasure are guaranteed. And as if that weren't enough, there's a whole armada of different Ear Tips in various sizes, fits and tonal tunings. Plus, the FiiO HB5 storage bag, a cleaning brush, and the handy magnetic clip to keep cables from tangling and twisting.
In the field of high-quality in-ear headphones, the manufacturer FiiO Electronics Technology Inc. Co. now offers an impressive product portfolio with various technologies. The new FiiO FH9 takes on the role of the flagship of the manufacturer's in-ear series. It belongs to the hybrid headphone systems that feature a dynamic driver as well as several BA drivers (Balanced Armature). The hybrid series represents the most successful series of FiiO in-ear speakers.Features and highlights of the FiiO FH9The new FiiO FH9 in-ear features a number of special characteristics, ranging from the construction to the enormous frequency response. 1 Dynamic driver with 13.6 millimetre DLC diaphragm 6 Balanced Armature (BA) drivers Frequency range: 10 Hertz to 40 Kilohertz Replaceable audio filter Efficiency 108 decibels Maximum input power / power handling: 100 milliwatts High-quality cable made of pure silver wire Interchangeable 2.5 millimetre, 3.5 millimetre or 4.4 millimetre plugs Titanium housingConstruction and principle of the FiiO FH9The FiiO FH9 consists of a high-quality titanium housing. This is of a semi-open design. Unlike other in-ears, which often have ventilation openings, the FiiO FH9's paceplate is permeable to air. This is achieved by protecting the open areas with a filigree mesh. The open design principle allows the dynamic driver to move completely freely. In this way, pressure equalisation occurs naturally, while distortion is also avoided. Both contribute to long and fatigue-free listening.FiiO FH9 package and deliveryAs is typical for the market, FiiO Electronics Technology Inc. includes a comprehensive range of accessories with its new FH9 headphones. In addition to the actual in-ears, the scope of delivery includes a high-quality case (FiiO HB5), a detachable cable, interchangeable plugs, three pairs of sound filters, numerous tips of various sizes and formats, cable clip and cleaning brush. The cable can be connected with several interchangeable plugs that can be quickly interchanged. Balanced plugs with 2.5 or 4.4 millimetres are included as well as a 3.5 millimetre unbalanced plug.Technology and sound of the FiiO FH9In the FH9 model, the manufacturer uses the Knowles drivers already known from other FiiO products for the BA drivers. The bass is generated by the dynamic DLC driver with its diameter of 13.5 millimetres. This bass provides a deep frequency response, which also has a high assertiveness in the upper bass. Depending on the productions you listen to, this can significantly enrich the sound image. With low bass recordings, the FH9 ensures that the existing bass is better perceived. If the production of the music is already bass-heavy, the bass can move to the foreground, but not at the expense of the highs and mids. In the mids, the Balanced Armature drivers from Knowles are finely tuned.The range of highs and super-highs is of balanced tuning in the FiiO FH9, which does not move too much to the foreground.Thanks to the included sound filters, it is always possible to adjust the sound to a certain extent to personal preferences. The bass filter provides a particularly dynamic and deep bass foundation. Those who prefer a high-resolution sound image with a high level of detail, especially in the treble, will benefit from the treble filter. The balanced filters provide a well-balanced sound image that transparently and clearly combines the advantages of the different sound worlds.Cabinet, workmanship and qualityThe workmanship and design of the FiiO FH9 are exceptional: the housing is made of titanium and has the noble matt grey finish typical of this material. The design is designed for a universal fit, as these are universal in-ear headphones. The manufacturer does not use a special anatomical design. FiiO relies on a high quality of workmanship and all components are optimally matched and joined together.The cable of the FiiO FH9A special feature is the cable with its interchangeable plug systems. The supplied cable is basically designed for balanced operation, but also supports unbalanced operation by changing the plugs. In this way, the cable or headphones can be operated with a classic 3.5 millimetre jack plug as well as with the 2.5 millimetre jack and 4.4 millimetre jack formats.Thanks to the two balanced plugs (2.5 and 4.4 millimetres) and the unbalanced 2.5 millimetre plug, there is a high degree of flexibility in the operation of the FiiO FH9. The plugs can be quickly exchanged at any time and the headphones can be adapted to a wide variety of playing partners.
Sufficient volume levels are also possible with the FiiO FH9 In Ear headphones in unbalanced operation with 3.5 millimetre jack. The characteristic sound pressure level is 108 dB / mW at an impedance of 18 ohms. In combination with the maximum power consumption of 100 mW, volumes of up to 128 dB are possible.The cable meets high standards in terms of construction and workmanship. The cable consists of 8 strands of 28 cores each and is made of monocrystalline silver. This provides a certain strength to the cable, which is, however, extremely comfortable to wear. The MMCX connectors are in stainless steel housings that can be rotated.Case and storage of the FiiO FH9The FiiO FH9 come in the FiiO HB5 case, which is already familiar from other headphones from the manufacturer. This high-quality case is made of imitation leather. The case is functional and precisely designed for the safe storage of the headphones. For this purpose, it offers an optimal size and compartments specially designed for the in-ears.
FiiO FX15
4 electrostatic + 1DD + 1BA hybrid in-ear monitor
FiiO's first IEMs with EST drivers
Hybrid configuration with six drivers
Four high-resolution SONION electrostatic drivers
One high-performance Knowles balanced-armature driver
One custom-designed dynamic 10mm DLC dome driver
Unique conceptual "Sound & Shape" design
Switch to turn on the EST drivers
FiiO's patented S. Turbo acoustic architecture
Professional DLP 3D printed resin ear cups
Ergonomic and lightweight
224-core high purity sterling silver cable
Secure MMCX connectors / Modular connector system
The new FiiO FX15 is a multi-driver hybrid IEM featuring a hybrid driver set with six drivers on each side. The pair houses a combination of three types of drivers:a 10mm DLC Dynamic driver,a Knowles Premium Balanced Armature driverand four Sonion EST drivers.The FiiO FX15 is FiiO's first product with an EST implementation. It has been designed with extreme precision and great professionalism to deliver high-end sound quality and a comfortable wearing experience. With professional tuning settings, the FiiO FX15 delivers great sound resolution and the ultimate music listening experience to its users.Premium sound with advanced architectureThe FiiO brand has years of experience in designing and developing premium audio devices. FiiO has designed the latest FX15 with a unique six-driver hybrid configuration that promises high-end sound to its users. The pair consists of a dedicated 10mm DLC dome dynamic driver for a powerful bottom end, a Knowles midrange/treble driver unit and four Sonion EST tweeter driver units. The drivers work together to produce a truly high-resolution sound output.FiiO's first implementation of electrostatic driversThe FiiO FX15 is FiiO's first implementation of high-resolution electrostatic drivers in IEMs. The brand has collaborated with SONION, one of the leading brands in the industry, to deliver high-quality and high-performance electrostatic driver units. Using four EST drivers on each side, the FiiO FX15 delivers a hugely detailed high frequency band.Switch on the EST drivers at willThe EST drivers are arranged here to enhance high-frequency extension and provide users with impressive high-frequency resolution. The pair features a switch that allows users to easily turn the EST drivers on and off.FiiO's patented S.Turbo acoustic designTo enhance the low frequency response produced by the dynamic driver unit, FiiO has equipped the pair with its patented S.Turbo acoustic design architecture. It incorporates an ultra-thin and long acoustic tube that significantly improves the pair's bass response.Professional tuning settingsThe FiiO FX15 is a true high-resolution in-ear monitor that promises high-end sound with its exquisite driver setup. The pair is tuned to deliver a balanced sound with powerful bass, beautiful mids and smooth but detailed highs.Exquisite looks with "Sound and Shape" design themeFiiO's FX15 IEMs feature an eye-catching ear cup design. The design of the pair is inspired by the "Sound and Shape" design theme. The pair looks beautiful with its designer covers.High-precision 3D-printed ear cupsFiiO has teamed up with a top brand in the industry and used their exquisite craftsmanship to create the beautiful FX15. The pair is made from high quality resin material, manufactured using high-precision DLP 3D printing technology. The shells are lightweight and promise to keep the listener comfortable.High purity cableTo ensure that the FiiO FX15 delivers premium sound performance, FiiO ships the pair with its high-purity 224-core sterling silver cable. It features an interchangeable connector system with 3.5mm and 4.4mm plugs included. The high-purity wire core allows for smooth signal transmission with low internal resistance for the audio signal.SpecificationsImpedance:24Ω@1kHzFrequency range: 20Hz-40kHzSensitivity: 103dB/mWConnector plugs: 4.4mm+3.5mm.
FiiO JH3One dynamic and two balanced armature drivers work in the FiiO JH3- Optimised 13.6mm diameter dynamic driver- Two matched BA drivers for incredible high resolution- Gold-plated 2-pin connectors for an ideal connection- Monocrystalline copper cable for interference-free transmission- Pressure equalisation system- Hi-Res certifiedA dynamic bass driver in the same format as in the big flagship FiiO IEM dynamic speakers. The newly designed surface structure of the drivers increases the magnetic flux by 20 percent for full and dynamic bass.The two built-in and customised Balanced Armature drivers are positioned as close as possible to the Sound Tube. This ensures the least possible loss of high frequencies.The combination of the three matched drivers in FiiO JH3 results in a sonically coherent picture that is, as is typical for hybrid IEMs, rather warm and yet analytically tuned.The CNC-machined aluminium lid with its louvre pattern is particularly impressive in sunlight.The built-in pressure compensation system balances the moving 13.6mm drivers and ensures a pressure-free listening and wearing experience in the ear. Nothing stands in the way of long listening sessions.The 0.78mm 2-pin connectors offer the option of multiple cable upgrades to a higher quality cable system or a wireless solution.High-purity monocrystalline copper with 120 strands in the supplied cables ensure resistance-free transmission of analogue music signals from the source to the driver.- Cable system: "over the ear- Frequency range 10 - 40 kHz- Driver: 1 x dynamic, 2 x balanced armature- Impedance 28 Ohm at 1kHz- Sensitivity 106dB at 1kHz@1mW- Maximum input power 100mW- Monocrystalline copper cable- Cable length approx. 120cm- Weight: 6 grams without cable
FiiO JH5
dynamic 4 BA hybrid IEMs
1 dynamic and 4 BA driver
10 mm carbon-based driver
Four custom BA drivers per ear
Three independent driver chambers
High-precision 3D-printed construction
Zinc alloy front panel
Bass reinforcement with negative feedback
0.78 2-pole detachable cable
detachable cable / Included 392-core silver-plated copper cable
Hi-Res Audio certified
High performance at a lower entry costFIIO x Jade Audio products have always been known for their value for money and high build quality, offering audiophiles affordable yet high quality equipment. The brand new FiiO JH5 is the latest result of FIIO and Jade Audio's years of experience in the audio field. The high-precision 3D-printed construction and exquisite zinc alloy front panel reflect the quality craftsmanship that has gone into the JH5. The acoustic design of the JH5 is inspired by the design of high-end IEMs such as the FH9 and FH7, with the aim of presenting music from genres as diverse as classical and pop in high-fidelity quality. At the heart of the FiiO JH5 is a 10mm carbon-based dynamic driver, seamlessly linked to the special balanced armature drivers that cover mid to ultra-high frequencies as the drivers are divided into three independent chambers. The FIIO JH5 is a truly affordable IEM with a highly accurate sound that lets you experience just how good dynamic BA hybrids can be.More carbon, more than amazing - 10 mm carbon-based dynamic driverThe quality of the dynamic driver is particularly important in hybrid IEMs as it forms the basis of the sound. The FiiO JH5's carbon-based 10mm dynamic driver is similar to those used in the popular FIIO "Little Conch" series headphones. However, this driver has been further optimized, making it a second generation model designed to work well with the rest of the acoustic design. The carbon-based driver can move quickly, resulting in excellent transient performance; all with minimal driver movement, resulting in less non-linear distortion.Delicate sound that captures even the finest details - Dynamic dual-cavity driverIn order to surpass the typical sound of its class, special attention was paid to optimizing and tuning the dynamic driver of the JH5 during development. The JH5's dynamic driver features a unique dual-layer cavity that allows damping systems in both the inner and outer chambers to precisely control airflow. The result is an extended yet fast bass response similar to that of a 'dynamic speaker'.Four customized BA drivers per ear - Tuned and matched BA drivers - For mid and high frequenciesTo ensure that the dynamic driver works well with the balanced armature drivers, the development team adopted design ideas from high-end hybrid IEMs such as the FH9 and FH7. Two special BA drivers handle the mid and high frequencies. These two BA drivers, together with the dynamic driver, have been specially designed to have a resonance peak at 2.8 kHz, which is also a resonance frequency formed by the shape of the human ear. The result is not only a smooth transition between the dynamic and balanced armature drivers, but also ensures that the transition between the different drivers is well matched to the shape of the human ear - resulting in a more natural soundstage and an overall smoother sound.Feel every plucked instrument string - Special ultra-high frequency BA driverTo achieve the desired sound quality, the development team saw fit to equip the JH5 with two custom ultra-high frequency (UHF) drivers. These two UHF drivers were placed closer to the sound nozzle, which in turn has a thicker inner surface, a shorter length and a slight curvature. The result of this design is that the FIIO JH5 is very wide in the treble and capable of producing ultra-high frequencies. It lets you feel every pluck of the instrument strings, bringing you much closer to the musical performance.High-energy, robust dynamics - Asymmetrical internal and external magnetic circuitsThe FIIO JH5 is equipped with a second-generation asymmetrical internal and external magnetic circuit to ensure that the driver has enough energy to transmit even the strongest audio dynamics. Compared to the traditional design with a single internal or external magnet, the magnetic circuits in the JH5 significantly increase the magnetic field density around the voice coil - resulting in more energy for a more robust sound as well as improved transient response. The JH5 uses powerful N52 neodymium magnets with 1.5T magnetic flux. Stronger magnets provide a more uniform magnetic field over a wider area, resulting in less distortion even when reproducing highly dynamic audio signals - resulting in a smooth, unrestricted sound.Interference-free - three independent driver chambersTo achieve maximum performance and produce a natural sound at all frequencies, the development team decided to take advantage of high-precision 3D printing to create three independent chambers, each housing a set of drivers that process a specific set of frequencies to reduce interference between the different drivers and thus reduce distortion. Thanks to the proprietary acoustic tube, the frequency response curve of the JH5 is smooth and free from distortion and sibilance caused by frequency response peaks.Smooth as jade, comfortable and skin-friendly - High-precision 3D printed constructionTo achieve better sound and superior comfort, the shell is made from medical grade resin that has undergone a high-precision DLP 3D printing process:- The high-precision 3D printing process with an accuracy of up to 0.05 mm ensures that even complex acoustic designs are consistent across all devices.- The medical-grade resin helps to ensure that the JH5s are robust, impact-resistant and have a long service life.Luxurious feel that can be felt with just one touchZinc die-cast alloy front panel The JH5 was developed as a relatively affordable IEM that not only sounds great, but also has excellent build quality. The sturdy yet lightweight magnesium alloy cover, which undergoes several processes such as liquid die casting, mirror electroplating and hand polishing, results in an IEM that simply exudes quality. Your fingers will notice it immediately when they touch the JH5.Negative feedback for bass enhancement- Pleasant sounding, great soundIf earphones made of synthetic resin are not manufactured carefully or have problems with their acoustic design, they can sound "closed" and disturb the eardrum. The dynamic driver of the FIIO JH5 is equipped with two magnets. When the driver vibrates, the sound is emitted from both the front and the rear of the driver with opposite phases. The JH5's bass amplifier with negative feedback directs the low-frequency sound waves emitted from the rear of the speaker to the front of the speaker. Compared to more typical acoustic designs, this special design allows for pressure relief at the front of the driver, reducing pain to the listener's eardrums caused by increased air pressure in a confined space. Such a design improves overall comfort, durability and sound quality and is made possible by high-precision 3D printing.Joseph Chief Engineer of FIIO IEM's R&D CenterHigh quality materials - 392 wire cable includedThe FIIO JH5 is supplied as standard with a cable made of high-purity silver-plated copper wire. All 14 wires are twisted into a small strand and 7 small strands form a large strand. With a total of 4 large strands, the JH5 cable has a total of 392 cores. The wires are each independently insulated and braided, which increases the conductive area and improves the high frequency details. The JH5 features a detachable 0.78mm 2-pin cable, providing numerous options for future upgrades. The 0.78 2-pin connector housings are angled and the cable ergonomically hugs your ear for a comfortable listening experience.Hi-Res Audio certifiedThe JH5 has been certified by the Japan Audio Society (JAS) and the Consumer Electronics Association (CEA) to faithfully reproduce your music.SpecificationsDriver: 10 mm carbon-based dynamic driver*1Customized balanced armature driver for mid and high frequencies*2Special balanced armature for ultra-high frequencies*2Frequency response: 20Hz-40kHzImpedance: 13Ω@1kHzSensitivity: 111dB/mW@1kHzCable material: 4 strands with a total of 392 wires made of silver-plated copperLength of the cable: About 1.2mWeight: Approx. 7.6g (without cable)Headphone connection: 0.78 2pin detachable cableAudio plug: High-quality gold-plated copper 3.5 mmScope of deliveryJH5 earphones, cable, case, Different eartips
